Buy | Sell Used Wooden Camera

Wooden Camera

This is a Bundle

ITEMS INCLUDED:
1 x D-Box (Canon C200, C200B, C300mkII, V-Mount) (Value $887.94)
1 x Battery Swing Bracket Only (for D-Box® Plus) (Value $265)

For a Video of this item, search for "Canon C300mkII D-Box" on YouTube and see the video from Wooden Camera.

D-Box:
D-Box (Canon C200, C200B, C300mkII, V-Mount) is a custom version of our popular D-Box that adds power distribution, standardized remote start/stop, for the Canon C200, C200B, and C300mkII. Allows for up to 5 simultaneous outputs with a maximum draw of 3A per output (24V outputs 3A max combined) and 10A total draw limited by an easily accessible fuse.

Two 12 inch (30cm) cables exit the power plate with one going to the 4pin power plug and the other going to the Remote port. There is a LANC control board inside the D-Box that communicates with the camera so that any ARRI standard start/stop can be used in the 3pin Fischer ports.

Please Note: In addition to the digital or glass fuse governing the output panels of the D-box, his product contains a secondary fuse for the D-tap ports of the attached battery plate. This fuse is located in a fuse holder within the plate and replacements can be purchased on Wooden Camera's website or other sites like Amazon.

Specifications:
Weight: 534 grams (1.18 lbs)
Dimensions: 90 x 146 x 43mm (3.5 x 5.7 x 1.7 inches)


Battery Swing
The Battery Swing Bracket Only (for D-Box Plus) provides mounts directly to the D-Box Plus to provide quick access the back of the camera by pulling the black pin and swinging open. The mounting bracket has integrated 15mm openings for mounting to 15mm LW rods.

Includes:
(3) M4 x 10mm Screws

Specifications:
Weight: 226.80g (0.5 lbs)
Dimensions: 50.8 x 114.3 x 45.7 mm (2 x 4.5 x 1.8 in)
